Glass Fiber Aluminum Foil Tape-Handashielding
Glass Fiber Aluminum Foil Tape-Handashielding
Glass Fiber Aluminum Foil Tape-Handashielding

Handa’s Glass Fiber Aluminum Foil Tape is a high-performance insulation and sealing solution engineered for demanding industrial, electrical, and HVAC applications. Designed with a reinforced fiberglass backing and high-purity aluminum foil face, it offers excellent thermal insulation, flame resistance, and optional EMI shielding.


Handa’s Glass Fiber Aluminum Foil Tape is a high-performance insulation and sealing solution engineered for demanding industrial, electrical, and HVAC applications. Designed with a reinforced fiberglass backing and high-purity aluminum foil face, it offers excellent thermal insulation, flame resistance, and optional EMI shielding.

This tape is ideal for environments requiring high mechanical strength, long-term durability, and resistance to heat, fire, moisture, and chemical exposure. Whether for aerospace insulation, duct wrapping, cable shielding, or fire-retardant applications, Handa’s glass fiber aluminum foil tape delivers both strength and reliability.


🔧 Product Overview

  • Product Name: Glass Fiber Reinforced Aluminum Foil Tape
  • Construction: Aluminum foil laminated to high-strength fiberglass cloth
  • Adhesive Options: Acrylic or high-temperature silicone adhesive
  • Adhesive Type: Conductive or non-conductive (optional)
  • Structure: Single-sided pressure-sensitive tape, available with or without release liner
  • Color: Silver
Glass Fiber Aluminum Foil Tape-Handashielding

📌 Key Features & Benefits

  • High Thermal Reflectivity
    Reflects up to 97% of radiant heat—ideal for thermal insulation and heat containment.
  • Flame Retardant & Fire-Resistant
    Meets international fire safety standards such as UL 723 and BS476 Part 6 & 7.
  • Reinforced Strength
    Fiberglass backing resists tearing, puncturing, and delamination under stress.
  • High Adhesion
    Acrylic or silicone adhesives bond securely to metal, plastic, foil insulation, and irregular surfaces.
  • Moisture & UV Resistant
    Withstands humid, outdoor, and corrosive conditions without degradation.
  • Moderate EMI Shielding
    Offers partial electromagnetic shielding when grounded; suitable for layered systems and cable wrapping.
  • Customizable Dimensions
    Widths from 10 mm to 1,200 mm, thicknesses from 60–150 μm, with die-cutting, liner, and printed branding options.

⚙️ Technical Specifications

ParameterValue
MaterialAluminum foil + Fiberglass cloth
Adhesive TypeAcrylic / Silicone
Adhesive SideSingle-sided
Thickness (total)0.06–0.15 mm
Carrier Thickness0.025–0.08 mm
Temperature Range–40 °C to 250 °C (peak 500 °C)
Flame ResistanceUL 723 / BS476 compliant
Shielding Effectiveness50–85 dB (when grounded)
Standard Width10–1200 mm (custom available)
Resistance≤0.3 Ω/inch

🎯 Applications

Handa’s glass fiber aluminum foil tape is widely used in:

  • HVAC Systems – Duct wrapping, joint sealing, and insulation
  • Power & Communication Cables – Heat shielding, bundling, and EMI containment
  • Automotive & Aerospace – Engine bay insulation, firewall protection, and flame barriers
  • Electronics – Shielding in assemblies sensitive to EMI/RFI
  • Building Materials – Fire-rated insulation boards, glass wool, and rock wool systems

🛠 Customization Options

Handa supports full OEM/ODM customization, including:

  • Widths: 10 mm to 1200 mm
  • Core Sizes: 1″, 1.5″, 2″, or 3″
  • Adhesive: Standard, conductive, or flame-retardant
  • Liner Options: PET, paper, or none
  • Formats: Rolls, sheets, die-cut parts
  • Private Label: Branding, logos, custom packaging available
Glass Fiber Aluminum Foil Tape-Handashielding

📦 Packaging & Delivery

  • Inner packaging: Roll with optional liner
  • Outer packaging: Shrink-wrapped or boxed
  • Lead time: 5–15 working days depending on quantity
  • Samples: Free test samples available upon request

🧩 Why Choose Handa?

At Handa Shielding, we bring decades of experience in EMI shielding and industrial insulation materials. Our glass fiber aluminum foil tape is engineered for high performance, consistency, and compatibility across a wide range of demanding environments.

With full in-house slitting, coating, and testing capabilities, we ensure every tape roll meets your exact application requirements—whether it’s temperature, shielding, adhesion, or dimensional accuracy.


📞 Get a Quote or Sample

Ready to upgrade your insulation or shielding solution? Contact our technical team today for technical datasheets, flame tests, sample rolls, or pricing details.

📧 Email: qinjunchang@handashielding.com
🌐 Website: www.handashielding.com
